2005-2010 FORD MUSTANG GT SUPERCHARGERS (4.6 3V)
THE MOST POWERFUL SUPERCHARGER SYSTEM FOR THE 3V MUSTANG BOLT ON 70-75% MORE POWER
ProCharger Superchargers offer the power and performance your 2005-2010 Ford Mustang GT (4.6 3V) craves! With kits boasting proven and durable features, including:
• HO and Stage II systems producing 10 psi of boost, 70-75%+ HP
• CARB certified systems available
• P-1SC-1 standard with system
• Quick and easy installation
• 3-core intercooler
• 8-rib belt standard
• Tuner Kits available
WHY CHOOSE PROCHARGER
• 30 Years of Innovation
• Largest Power Gains
• Coolest Charge Air Temps
• Street Legal Systems
• Most Wins and Championships
• OEM Quality and Appearance
• Best Service & Product Support
• Most Kits Ship Within 2-3 Days
• Proudly made in the USA
Check out all of our 4.6 Mustang superchargers or click below to see the many advantages of using a ProCharger supercharger.”
When it comes to forced air power adders for the latest 4.6L 3V Mustangs, ProCharger is the Ultimate Mustang Power Adder. With power, performance and reliability others can only dream of, ProCharger offers several intercooled supercharger solutions for the boost-friendly 3V Mustangs: a High Output (HO) Intercooled System and a Stage II Intercooled System.
Both the HO Intercooled and Stage II Intercooled systems for 3V Mustangs utilize the patented, proven and self-contained P-1SC-1 ProCharger, an exclusive dedicated, 8-rib drive supercharger drive system, a highly-effective, 3-core air-to-air intercooler, OEM-quality mounting brackets, eight larger fuel injectors, higher capacity fuel system, tuning and all necessary supercharger and intercooler tubes for installation onto Mustangs with no major modifications to your car or engine. ProCharger Systems are 100% complete and require no additional hardware.
CHOOSE THE SYSTEM BEST FOR YOU
HO INTERCOOLED SYSTEM
• ProCharger P-1SC-1 (satin standard finish), warranty available
• ProCharger’s patented, self-contained oiling design requires no external oil lines
• 3-core intercooler standard
• ProFlow blow-off valve
• 8-rib belt drive (standard)
• System is 100% complete with OEM appearance and quality
• 525+ HP with 10 psi
• Intercooled Supercharger system with 6-rib shared drive available
• Hand held tuner provided
• Part # for HO system: 1FP214-SCI
• Part # for shared drive system : 1FP311-SCI
OPTIONS
• Polished or Black finish for the supercharger, crank support and/or bracket
• Polished finish for throttle body tube inlet (satin standard finish)
• Helical gear set for noise reduction (P-1SC-1, D-1SC)
• Race blow-off valve upgrade (Red or Black finish)
• With D-1SC ProCharger (replacing P-1Sc-1) (tuner kit only)
STAGE II INTERCOOLED SYSTEM
• ProCharger P-1SC-1 (satin standard finish)
• ProCharger’s patented, self-contained oiling design requires no external oil lines
• 3-core intercooler standard
• ProFlow blow-off valve
• 8-rib belt drive
• System is 100% complete with OEM appearance and quality
• 600+ HP with higher boost levels
• Hand held tuner provided
• Part # : 1FP211-SCI
OPTIONS
• With F-1D, F-1, F-1A ProCharger (replacing P-1SC-1) (Stage II only)
• With F-1A-94, F-1C, or F-1R (replacing P-1SC-1) (Stage II tuner kit only)
• 800+ HP intercooler upgrade (Stage II only)
• Identical to HO Intercooled System
INTERCOOLED SERPENTINE RACE KIT
• ProCharger F-1A (satin standard finish)
• ProCharger’s patented, self-contained oiling design requires no external oil lines
• 800+ HP rated intercooler
• Race blow-off valve
• Serpentine 12-rib drive standard
• Part # for F-1D, F-1, or F-1A: 1FR200-F1
• Part # for F-1A-94, F-1C, or F-1R: 1FW212-SCI
OPTIONS
• With F-1A-94, F-1C, or F-1R (replacing F-1A) (Race Kits only)
• Identical to HO Intercooled System
HAVE VEHICLE MODS? GET A TUNER KIT!
Tuner Kits: These kits make sense for someone wanting to perform custom tuning of the car and push the envelope in performance. Will most likely be experimenting with alternative fuels such as 93 octane, race fuel, E85 fuel, and methanol supplemental fuel. In addition, possibly changing engine components like heads, headers, exhaust, and cams for the engine. No tuning or fuel components provided.
Tuner Kits are identical hardware to full systems, except they do not include tuning or fuel components. Tuner kits are highly customized by the end user and are, therefore, not emissions certified.
- Intercooled Supercharger Tuner Kit with P-1SC-1 – P/N 1FP301-SCI
- HO Tuner Kit – P/N 1FP204-SCI
- Stage ll Tuner Kit – P/N 1FP202-SCI
P-1X/D-1X UPGRADE
The ProCharger P-1X and D-1X head units feature the robust, self-contained gearcase that is standard on most ProCharger models, but with a new aerodynamic compressor design that creates cooler charge air temperatures and more horsepower at the same boost level than our industry-standard P-1SC-1 and D-1SC. This higher efficiency design was engineered to be a bolt-in replacement for P-1SC-1 and D-1SC equipped systems and has even greater max-power potential.
BOLT ON 11'S
This intercooled ProCharger system produces an industry-leading 70 – 75% power gain on an otherwise stock engine running high-quality pump gas with 10 psi of intercooled boost. That’s enough additional power to propel your otherwise stock Mustang to 11-second 1/4-mile passes.
FEATURED BUILDS
?version=3&mute=1&loop=1&playlist=" frameborder="0" allow="accelerometer; autoplay; encrypted-media; gyroscope; picture-in-picture" allowfullscreen >
?version=3&mute=1&loop=1&playlist=" frameborder="0" allow="accelerometer; autoplay; encrypted-media; gyroscope; picture-in-picture" allowfullscreen>
GET YOUR PROCHARGER POWER TODAY!
BUILD & PRICE
Kits starting at $6,799. Pricing on these units vary by configuration. Configure your purchase now.
FIND A DEALER NEAR YOU
Looking to make a purchase or a shop to install? We have a large group of dealers ready to serve you with your ProCharger needs. Click below to find a dealer near you!
SPEAK TO AN EXPERT
Click to call our sales staff or email us if you need any help. We will be happy to assist you with any questions you may have.
Mon – Fri 8am – 5:30pm CST
Phone – (913) 338-2886
Sales Email – [email protected]
INSTALLATION MANUAL
HO INTERCOOLED SYSTEMS & KITS (2005-2010)
STAGE II INTERCOOLED SYSTEMS & KITS (2005-2008)
Get a Catalog
Our catalogs feature much of this detail. You can either download a copy or have one mailed to you free of charge.
CALIFORNIA EMISSIONS COMPLIANCE INFO (CARB)
ProCharger now offers a CARB EO system for the 2010-2005 Ford Mustang GT (4.6 3V). These products are intended for racing or off road applications only. California approved products for street legal use (complete systems) will have an associated CARB EO# for compliance. For a full list of California and 50 state street legal systems, click below.
MORE ABOUT PROCHARGING FORD VEHICLES
EMISSIONS COMPLIANCE
ProCharger offers Executive Orders for Emissions Compliance (EO) from California Air Resources Board (CARB) for many of our most popular car, truck and SUV applications. If you live in California, we can only sell you products with EO certification. Check out our full list of EO offerings.
